206-26-00400 206-26-00401 Final Drive Gearbox For PC220-7 PC230 PC220

206-26-00400 206-26-00401 Final Drive Gearbox For PC220-7 PC230 PC220

  • 206-26-00400 206-26-00401 Final Drive Gearbox For PC220-7 PC230 PC220
206-26-00400 206-26-00401 Final Drive Gearbox For PC220-7 PC230 PC220
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 206-26-00400 206-26-00401
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Negotiated
Packaging Details: Wooden Case, 80*80*90
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C, ALIPAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Swing Gearbox Swing Machinery Part Number: 206-26-00400 206-26-00401
Used For: PC220 PC230 Condiction: All New, OEM
Warrenty: 6-12 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
Port: Huangpu, Guangzhou Weight: 250 Kgs With Packing
High Light:

206-26-00400 Final Drive Gearbox

,

206-26-00401 Final Drive Gearbox

,

PC220-7 206-26-00400

206-26-00400 206-26-00401 Swing Gearbox Swing Machinery PC220 PC230





Pos. Part No Qty Parts name Comments
  206-26-00401 [1] SWING MACHINERY A. Komatsu 226.1 kg.
  ["SN: 60601-@"] analogs:["2062600400"] |1.
  206-26-00400 [1] SWING MACHINERY A. Komatsu 226.1 kg.
  ["SN: 60001-60600"] analogs:["2062600401"] |1.
1. 206-26-71490 [1] CASE Komatsu 105.42 kg.
  ["SN: 60001-60600"]
2. 07029-00000 [1] VALVE Komatsu 0.09 kg.
  ["SN: 60001-60600"] analogs:["6127613890"]
3. 20Y-26-22330 [1] BEARING Komatsu China 3.28 kg.
  ["SN: 60001-60600"] analogs:["20Y2622331", "20Y2622430"]
4. 206-26-71240 [1] BEARING Komatsu 12.83 kg.
  ["SN: 60001-60600"]
5. 206-26-71460 [1] SHAFT Komatsu China
  ["SN: 60001-60600"]
6. 07012-00115 [1] SEAL Komatsu 0.127 kg.
  ["SN: 60001-60600"]
7. 206-26-71310 [1] SPACER Komatsu 0.81 kg.
  ["SN: 60001-60600"]
8. 07000-15310 [1] O-RING Komatsu China 0.035 kg.
  ["SN: 60001-@"] analogs:["0700005310"]
9. 206-26-71480 [1] CARRIER Komatsu 10.88 kg.
  ["SN: 60001-@"]
10. 206-26-71440 [4] GEAR Komatsu 1.91 kg.
  ["SN: 60001-@"]
11. 22U-26-21320 [8] BEARING Komatsu 1.1 kg.
  ["SN: 60036-@"]
  22U-26-21330 [8] BEARING Komatsu China
  ["SN: 60001-60035"] |11.
12. 206-26-71520 [8] THRUST WASHER Komatsu 0.1 kg.
13. 206-26-71510 [4] PIN Komatsu 0.97 kg.
  ["SN: 60001-@"]
14. 20Y-26-21330 [4] PIN Komatsu China 0.1 kg.
  ["SN: 60001-@"]
15. 20Y-26-21240 [1] PLATE Komatsu 5.1 kg.
  ["SN: 60001-@"]
16. 112-32-11211 [1] BOLT¤ SHOE Komatsu 0.09 kg.
  ["SN: 60001-@"]
17. 206-26-71452 [1] GEAR Komatsu 28.79 kg.
  ["SN: 60283-@"]
  206-26-71450 [1] GEAR Komatsu 28.79 kg.
  ["SN: 60001-60282"] analogs:["2062671452"] |17.
18. 20K-22-11190 [1] O-RING Komatsu 0.02 kg.
  ["SN: 60001-@"] analogs:["20G2211190"]
19. 01010-81440 [22] BOLT Komatsu 0.073 kg.
  ["SN: 60001-@"] analogs:["0101061440", "0101031440", "0101051440", "0104031440"]
20. 01643-31445 [22] WASHER Komatsu 0.019 kg.
  ["SN: 60001-@"] analogs:["0164301432"]
21. 206-26-71430 [1] GEAR Komatsu 2.33 kg.
  ["SN: 60001-@"]
22. 04260-01270 [1] BALL Komatsu OEM 0.009 kg.
  ["SN: 60001-@"]
23. 206-26-71470 [1] CARRIER Komatsu 3.9 kg.
  ["SN: 60001-@"]
24. 206-26-71420 [3] GEAR Komatsu 0.83 kg.
  ["SN: 60001-@"]
25. 20Y-27-22210 [3] BEARING Komatsu China 0.12 kg.
  ["SN: 60001-@"] analogs:["20Y2721260"]
26. 22U-26-21230 [6] WASHER,THRUST Komatsu 1 kg.
  ["SN: 60001-@"]
27. 206-26-71210 [3] PIN Komatsu 0.42 kg.
  ["SN: 60001-@"]
28. 04064-03515 [6] RING Komatsu 0.005 kg.
  ["SN: 60001-@"]
29. 206-26-71350 [1] HOLDER Komatsu 0.21 kg.
  ["SN: 60001-@"]
30. 206-26-71410 [1] GEAR Komatsu 0.83 kg.
  ["SN: 60001-@"]
31. 206-26-71340 [1] PLATE Komatsu 0.09 kg.
  ["SN: 60001-@"]
32. 20Y-26-31510 [1] COVER Komatsu 7.3 kg.
  ["SN: 60001-@"]
33. 01010-81035 [6] BOLT Komatsu 0.033 kg.
  ["SN: 60001-@"] analogs:["801015556", "01010D1035", "0101051035"]
34. 01643-51032 [6] WASHER Komatsu 0.17 kg.
  ["SN: 60001-@"] analogs:["R0164351032"]



206-26-00400 206-26-00401 Final Drive Gearbox For PC220-7 PC230 PC220 0

FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.



206-26-00400 206-26-00401 Final Drive Gearbox For PC220-7 PC230 PC220 1

206-26-00400 206-26-00401 Final Drive Gearbox For PC220-7 PC230 PC220 2

206-26-00400 206-26-00401 Final Drive Gearbox For PC220-7 PC230 PC220 3

206-26-00400 206-26-00401 Final Drive Gearbox For PC220-7 PC230 PC220 4
