296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL

296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL

  • 296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL
  • 296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL
296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 296-6253 296-6250 3530528 3530500 1994487
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden Case
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Swing Gearbox Part Number: 296-6253 296-6250 3530528 3530500 1994487
Used For: E330D E345C E345D E345DL Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

296-6253 Excavator Swing Gearbox

,

296-6250 Excavator Swing Gearbox

,

E330D 3530528

296-6253 296-6250 3530528 3530500 1994487 E330D E345C E345D E345DL Swing Drive Without Motor



Part Name Swing Drive Without Motor
Part Number 296-6253 296-6250 3530528 3530500 1994487
Used For E330D E345C E345D E345DL
Warrenty 3 Months
After Warranty Video technical support Online support Free Spare parts
Pos. Part No Qty Parts name Comments
1 4H-6112 [1] BREATHER (SWING DRIVE)
2 4I-7464 [4] GEAR-PLANETARY (25-TEETH)
3 4I-7466 [4] GEAR-PLANETARY (23-TEETH)
4 4I-7467 [1] GEAR-RING (72-TEETH)
5 6V-7238 [1] VALVE-SHUTOFF
6 7I-7728 [1] CARRIER-PLANETARY
7 7Y-0597 [1] SPACER-SPECIAL
8 7Y-1238 [1] CARRIER
9 093-1730 [2] RING-RETAINING
10 094-1509 [4] SHAFT-PLANETARY
11 094-1528 [8] WASHER (53X84X1-MM THK)
12 095-1806 [1] BEARING-ROLLER
13 096-2653 [1] RING-RETAINING
14 096-4339 [1] BEARING AS-ROLLER
15 110-7216 [1] GEAR-SUN (24-TEETH)
16 114-1383 [4] SHAFT-PLANETARY
17 114-1398 [1] GAUGE-OIL LEVEL (SWING DRIVE)
18 114-1399 [1] PIPE-GAUGE
19 114-1401 [1] COVER-HOUSING
20 114-1403 [1] CAGE
21 136-2802 [2] CONNECTOR
22 136-2803 [2] CLIP
23 169-5534 [1] HOUSING
24 169-5535 [1] GEAR-SUN (20-TEETH)
25 227-6108 [1] SHAFT-PINION
26 227-6215 [1] BOSS (1/4-18-THD)
27 296-6251 I [1] HOSE AS
28 093-1731 [1] RING-RETAINING
29 094-0584 [8] WASHER (40.3X72X1-MM THK)
30 199-4582 [4] BEARING AS
31 095-0886 [4] PIN-SPRING
32 509-6676 [4] PIN-SPRING
33 135-9044 [2] SEAL-LIP TYPE
34 3K-0360 [1] SEAL-O-RING
35 5P-2235 [1] SEAL-O-RING
36 191-2513 [8] BEARING AS-ROLLER
37 7Y-0595 [1] SPACER (58X79.6X6-MM THK)
38 7Y-1434 [1] SPACER (40X69.5X6-MM THK)
39 453-3447 M [8] BOLT (M12X1.75X40-MM)
40 451-2182 [10] WASHER-HARD (13.5X25.5X3-MM THK)
41 8T-4244 M [1] NUT (M12X1.75-THD)
42 453-3446 M [1] BOLT (M12X1.75X35-MM)
43 453-2843 M [16] BOLT (M16X2X180-MM)
44 451-2175 [16] WASHER-HARD (17.5X30X3.5-MM THK)
45 1U-8846 B   SEALANT-GASKET
  B   USE AS REQUIRED
  I   REFER TO HYDRAULIC INFORMATION SYSTEM
  M   METRIC PART



296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL 0

296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL 1



296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL 2

296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL 3296-6253 296-6250 3530528 3530500 1994487 Excavator Swing Gearbox Fit E330D E345C E345D E345DL 4









FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.
