EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036

EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036

  • EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036
  • EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036
  • EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036
  • EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036
  • EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036
EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 3070443 3055594 2036830 2028036 EX120-5 EX100 EX135UR
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden Case
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Shaft Part Number: 3070443 3055594 2036830 2028036
Used For: EX120-5 EX100 EX135UR Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

EX135UR Travel Motor Drive Shaft

,

3055594 Travel Motor Drive Shaft

,

2028036 Travel Motor Drive Shaft

3070443 3055594 2036830 2028036 EX120-5 EX100 EX135UR Planetary Gear Parts Travel Motor Drive Shaft

Part Name Shaft
Part No. 3070443 3055594 2036830 2028036
Used For EX120-5 EX100 EX135UR
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts
Pos. Part No Qty Parts name Comments
  -9148472 [1] MOTOR;OIL <for transportation>
  9132360 [1] MOTOR;OIL I 9148472 9132360<for assembly of machine>
0 1020617 [1] HOUSING
1 4212841 [1] SEAL;OIL
4 3070443 [1] SHAFT
5 959499 [2] RING;RETAINING
6 4343872 [1] BRG.;ROL.
9 9147525 [1] PLATE ASS'Y
09A. +++++++ [1] PLATE
09B. +++++++ [2] PIN
11 4212842 [1] PIN;KNOCK
14 3072797 [1] PLATE;SWASH
15 4264312 [2] PISTON;SERVO I 4416040
15 4264312 [2] PISTON;SERVO
15 4416040 [2] PISTON;SERVO
15 4416040 [2] PISTON;SERVO
17 3058406 [1] RETAINER Y 3078124
17 3078124 [1] RETAINER
19 2028344 [1] ROTOR
20 4312681 [9] SPRING;COMPRES.
21 3065176 [1] BUSHING
23 8060510 [9] PISTON
25 4332191 [1] SPACER
26 3032432 [4] PLATE
27 3043240 [3] PLATE;FRICTION
28 3070481 [1] PISTON T 3076389
28 3070481 [1] PISTON T 4372710
28 3070481 [1] PISTON T 4372711
28 3076389 [1] PISTON
29 4372710 [1] O-RING
29 A811155 [1] O-RING
31 4311391 [1] O-RING
31 4372711 [1] O-RING
33 3043242 [1] SPRING;DISC
35 4506415 [3] O-RING
36 4244542 [1] O-RING
38 -9148471 [1] VALVE;BRAKE<for transportation>
38 9132208 [1] VALVE;BRAKE<for assembly of machine> I 9148471 9132208A
39 4361865 [1] RING;BACK-UP
40 4234840 [1] BRG.;NEEDLE
41 4311393 [1] RING;BACK-UP
42 3047922 [1] PLATE;VALVE
43 4271350 [2] PIN;KNOCK
46 M341640 [9] BOLT;SOCKET



EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036 0



EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036 1

EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036 2EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036 3EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036 4EX120-5 EX100 EX135UR Travel Motor Drive Shaft  3070443 3055594 2036830 2028036 5











FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.
