VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing

VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing

  • VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing
  • VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing
  • VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing
  • VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing
VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden Case
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Motor Housing Part Number: VOE14506956 VOE14501795 VOE14501796 VOE14506991
Used For: EC290 Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

 EC290 Travel Reduction Motor Housing

,

VOE14506956 Travel Reduction Motor Housing

,

VOE14506991 Excavator Travel Motor Parts

VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing​



Part Name Motor Housing
Part Number VOE14506956 VOE14501795 VOE14501796 VOE14506991
Used For EC290
Warrenty 3 Months
After Warranty Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
  VOE14509996 [1] Travel motor
1 VOE14506950 [1] Spool
2 VOE14506954 [1] Shaft
3 VOE14506955 [1] Bearing
4 VOE14506991 [1] Casing
5 VOE14506958 [2] Pivot
6 VOE14506959 [1] Piston
7 VOE14506962 [1] Plate
8 VOE14506967 [9] Spring
9 VOE14506968 [1] Spacer
10 VOE14506970 [1] Guide
11 VOE14506972 [1] Plate
12 VOE14506974 [9] Piston
  VOE14506975 [1] Piston
  VOE14506977 [1] Pad
13 VOE14506980 [1] Pin
14 VOE14506982 [2] Plate
15 VOE14506984 [1] Plate
16 VOE14506986 [1] Piston
17 VOE14506988 [1] O-ring
18 VOE990849 [2] O-ring
19 VOE14506956 [1] Casing
20 VOE14506993 [1] Spool
21 VOE14506994 [1] Spring
22 VOE14506995 [1] Plug
23 VOE14507000 [1] Spacer
24 VOE14507001 [1] Filter
25 VOE14552644 [1] Cylinder
  VOE14506965 [1] Cylinder block
  VOE14506978 [1] Plate
26 VOE14509997 [1] Spool
27 VOE14640025 [1] Roller bearing
28 SA7242-10520 [2] Washer
29 SA7242-10530 [2] Spring
30 SA7242-10540 [2] Cover
31 SA7242-10560 [1] Pin
32 SA7242-10590 [1] Seal
33 SA7242-10680 [1] Piston rod
34 SA7242-10710 [2] Clamping plate
35 SA7242-10720 [2] Guard
36 SA7242-10750 [1] Screw
37 VOE14565167 [10] Spring
38 VOE14551526 [5] Pin
39 VOE14560637 [9] Plug
40 SA7242-11090 [1] Screw
41 SA7242-11290 [1] Plug
42 SA7242-11560 [1] Spring
43 SA7242-11580 [2] Relief valve
44 SA9016-11209 [8] Hex. socket screw
45 SA9016-12010 [4] Hex. socket screw
46 SA9016-22019 [2] Hex. socket screw
47 VOE997410 [1] Hexagon nut
48 VOE14883837 [7] Plug
49 SA9415-11041 [2] Plug
50 VOE983497 [2] O-ring
51 VOE983502 [7] O-ring
52 VOE983505 [1] O-ring
53 VOE983507 [2] O-ring
54 VOE990557 [2] O-ring
55 VOE983509 [1] O-ring
56 SA9511-1210A [1] O-ring
57 VOE990585 [2] O-ring
58 VOE914472 [1] Snap ring
59 SA9541-02090 [1] Retaining ring
60 SA9676-73200 [2] Ball
100 VOE14513325 [1] Sealing Kit



VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 0

VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 1

VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 2VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 3VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 4VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 5











FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.



VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 6VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 7VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 8VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 9VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 10VOE14506956 VOE14501795 VOE14501796 VOE14506991 EC290 Parts Travel Reduction Motor Housing Travel Gearbox Housing 11
