SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drivel

SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drivel

  • SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drivel
  • SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drivel
SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drivel
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: SA7117-30180 VOE14531072 VOE14517068 VOE14533206
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Flexible Coupling Gear Part Number: SA7117-30180 VOE14531072 VOE14517068 VOE14533206
Used For: EC160 EC210 EC220 EC140 Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/TNT/UPS/SEA/AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light: SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear

SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drive


Part Name Flexible Coupling Gear
Part Number SA7117-30180 VOE14531072 VOE14517068 VOE14533206
Used For EC160 EC210 EC220 EC140
Warrenty 3 Months
After Warranty Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
  VOE14528733 [1] Travel gearbox
1 SA7117-30100 [1] Housing SER NO 10001-10693
  VOE14522475 [1] Housing SER NO 10694-
2 SA7117-30110 [2] Ball bearing
3 SA7117-30120 [1] Seal SER NO 10001-10693
  VOE14729840 [1] Seal SER NO 10694-
4 SA7117-30140 [1] Shim T=0.1
  SA7117-30150 [1] Shim T=0.9
  SA7117-30160 [1] Shim T=1.0
  SA7117-30170 [1] Shim T=1.2
5 SA7117-30130 [1] Retainer
6 VOE997446 [12] Hexagon screw
7 SA9324-21212 [2] Pin
8 SA7117-30190 [1] Ring gear
9 SA7117-30180 [1] Flexible coupling
10 SA7117-30200 [1] Carrier No 2 SER NO 10001-10693
  VOE14528723 [1] Planet carrier No 2 SER NO 10694-
11 SA7117-30210 [1] Planet carrier
12 SA7117-30240 [4] Planetary Gear
13 SA7117-30230 [8] Needle bearing
14 SA7117-30220 [8] Thrust washer
15 SA7117-30250 [4] Pin SER NO 10001-10693
  VOE14528724 [4] Pin SER NO 10694-
16 SA9325-06012 [4] Spring pin
17 SA7117-30260 [1] Thrust ring
18 SA7117-30270 [1] Carrier No 1 SER NO 10001-10693
  VOE14528727 [1] Planet carrier No 1 SER NO 10694-
19 SA7117-30280 [1] Carrier SER NO 10001-10693
  VOE14528728 [1] Planet carrier SER NO 10694-
20 SA7117-30290 [1] Sun gear
21 SA7117-30300 [1] Ring
22 SA7117-30340 [3] Planetary gear
23 SA7117-30320 [3] Needle bearing
24 SA7117-30310 [6] Thrust washer
25 SA7117-30360 [3] Pin
26 VOE951955 [3] Spring pin
27 SA7117-30260 [1] Thrust ring
28 VOE14602566 [1] Cover
29 SA7117-15230 [1] Pad
30 SA7117-30370 [20] Hexagon screw
31 SA9023-11004 [2] Set screw
32 VOE14883848 [3] Plug
33 SA7117-30330 [1] Sun gear
34 VOE983524 [3] O-ring



SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drivel 0



SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drivel 1

SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drivel 2SA7117-30180 VOE14531072 VOE14517068 VOE14533206 EC160 EC210 EC220 EC140 Flexible Coupling Gear Excavator Final Drivel 3









FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount),Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all ,we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely , or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass’y/parts, swing gearbox/ass’y. If you need other excavator parts, we also can supply as your requirements.
