E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594

E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594

  • E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594
  • E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594
E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 169-5590 1912684 1695592 1695594 E324D E320C E322C
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: 3rd Sun Gear Part No.: 169-5590 1912684 1695592 1695594
Used For: E324D E320C E322C Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

E324D Travel Gearbox 3rd Sun Gear

,

E322C Travel Gearbox 3rd Sun Gear

,

1695594 Travel Gearbox 3rd Sun Gear

169-5590 1912684 1695592 1695594 E324D E320C E322C Travel Gearbox 3rd Sun Gear Planetary Gear Parts Excavator



Part Name 3rd Sun Gear
Part No. 169-5590 1912684 1695592 1695594
Used For E324D E320C E322C
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts
Pos. Part No Qty Parts name Comments
1 7Y-1434 [1] SPACER (40X69.5X6-MM THK)
2 096-1773 B [1] SHIM (0.15-MM THK)
  096-1774 B [1] SHIM (0.3-MM THK)
  096-1775 B [1] SHIM (0.4-MM THK)
  096-1776 B [1] SHIM (0.5-MM THK)
  096-1777 B [1] SHIM (0.6-MM THK)
  096-1778 B [1] SHIM (0.7-MM THK)
  096-1779 B [1] SHIM (0.8-MM THK)
  096-1780 B [1] SHIM (1-MM THK)
  096-1781 B [1] SHIM (1.6-MM THK)
3 148-4715 [1] GEAR-COUPLING (55-TEETH)
4 114-1539 [6] PIN-DOWEL
5 191-3235 [1] HOUSING
6 168-8451 [2] BALL BEARING
7 114-1497 [1] SEAL GP-DUO-CONE
8 191-3236 [1] HOUSING
9 095-1270 M [2] SETSCREW-SOCKET (M12X1.75X30-MM)
10 102-6456 [1] GEAR-RING (79-TEETH)
11 6V-3303 M [14] BOLT (M16X2X60-MM)
12 7Y-0223 [3] SHAFT-PLANETARY
13 094-1542 [6] BEARING-ROLLER
14 7Y-1431 [3] GEAR-PLANETARY (30-TEETH)
15 094-1528 M [6] WASHER (53X84X1-MM THK)
16 095-0891 [6] PIN-SPRING
17 6I-6585 [3] GEAR-PLANETARY (44-TEETH)
18 094-0616 [3] BEARING AS-ROLLER
19 3E-2338 [2] PLUG-PIPE
20 7M-8485 [2] SEAL-O-RING
21 7Y-1426 [1] COVER
22 7Y-0225 [3] SHAFT-PLANETARY
23 094-0611 [6] WASHER (47.3X76X1-MM THK)
24 094-0580 [1] PLATE (10-MM THK)
25 6I-6583 [1] GEAR-SUN (13-TEETH)
26 7Y-1430 [1] GEAR-SUN (17-TEETH)
27 7Y-1558 [1] SPACER (90X119.6X7.5-MM THK)
28 7Y-1432 [1] CARRIER
29 7X-2568 M [16] BOLT (M20X2.5X180-MM)
30 8T-4123 [16] WASHER (3.62X5.75X0.375-MM THK)
31 1U-8846 B   SEALANT-GASKET
32 6D-0692 [1] SEAL-O-RING
33 102-6454 [1] GEAR-RING (104-TEETH)
34 7Y-1433 [1] CARRIER
  B   USE AS REQUIRED
  M   METRIC PART



E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 0

E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 1

E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 2E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 3











FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.



E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 4E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 5E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 6E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 7E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 8E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 9

E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 10E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 11E324D E320C E322C Travel Gearbox 3rd Sun Gear169-5590 1912684 1695592 1695594 12
