Guangzhou Menzeh Machinery Parts Co., Ltd.
| Place of Origin: | GUANGZHOU CHINA |
| Brand Name: | MENZEH GEARS |
| Certification: | CE |
| Model Number: | 191-2674 1912676 1695590 1719387 1912683 Excavator E320 E322C E324D |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | Negotiated |
| Packaging Details: | BOX, Wooden |
| Delivery Time: | 1-3 working Days |
| Payment Terms: | Western Union, T/T, L/C,ALI PAY |
| Supply Ability: | 500 pcs per Day |
| Part Name: | Gear Sun | Part Number: | 191-2674 1912676 1695590 1719387 1912683 Excavator |
|---|---|---|---|
| Used For: | E320 E322C E324D | Condiction: | All New OEM |
| Warrenty: | 3 Months | Shipping: | DHL/TNT/UPS/SEA/AIR Shipping |
| Port: | Huangpu Guangzhou | After Warranty: | Video Technical Support Online Support Spare Parts |
| High Light: | 1912683 Excavator Final Drive Parts,1695590 Excavator Final Drive Parts,E324D Gear Sun |
||
191-2674 1912676 1695590 1719387 1912683 Excavator E320 E322C E324D Gear Sun 20T Lower 14T Upper
| Part Name | Sun Gear |
| Part No. | 2025958 0462305 8970443720 2022128 2028644 |
| Used For | EX100 EX200-2 |
| Warrenty | 3 months |
| After Warranty | Video technical support Online support Free Spare parts |
| Pos. | Part No | Qty | Parts name | Comments |
| 1 | 169-5586 | [1] | HOUSING-MOTOR | |
| 2 | 207-1571 | [1] | SEAL GP-DUO-CONE | |
| 2A. | 214-3570 | [2] | RING-TORIC | |
| 2B. | Z | [2] | SEAL-RING | |
| 3 | 168-8452 | [2] | BALL BEARING | |
| 4 | 7Y-0595 | [3] | SPACER (58X79.6X6-MM THK) | |
| 5 | 169-5596 | [1] | STOP | |
| 6 | 171-9298 | [1] | SEAL-O-RING | |
| 7 | 191-2676 | [1] | GEAR-RING (72-TEETH) | |
| 8 | 169-5599 | [1] | CARRIER-PLANETARY | |
| 9 | 169-5590 | [1] | GEAR-SUN (24-TEETH) | |
| 10 | 191-2570 | [6] | BEARING AS (CAGED ROLLER) | |
| 11 | 169-5594 | [1] | GEAR-RING (65-TEETH) | |
| 12 | 7M-8485 | [2] | SEAL-O-RING | |
| 13 | 3E-2338 | [2] | PLUG-PIPE | |
| 14 | 191-2678 | [1] | CARRIER AS | |
| 15 | 093-1731 | [2] | RING-RETAINING | |
| 16 | 169-5589 | [1] | GEAR-SUN (24-TEETH) | |
| 17 | 094-0578 B | [1] | PLATE (8-MM THK) | |
| 18 | 094-0579 B | [1] | PLATE (9-MM THK) | |
| 19 | 094-0580 B | [1] | PLATE (10-MM THK) | |
| 20 | 191-2674 | [1] | GEAR-SUN (25-TEETH) | |
| 21 | 191-2675 | [3] | GEAR-PLANETARY (20-TEETH) | |
| 22 | 096-0433 | [3] | RING-RETAINING | |
| 23 | 171-9297 | [6] | WASHER (34.3X62X1-MM THK) | |
| 24 | 191-2677 | [3] | BEARING AS (CAGED ROLLER) | |
| 25 | 9X-6032 M | [12] | BOLT-SOCKET HEAD (M10X1.5X30-MM) | |
| 26 | 179-8733 M | [16] | BOLT (M20X2.5X170-MM) | |
| 27 | 8T-4123 | [16] | WASHER (22X35X3.5-MM THK) | |
| 28 | 199-4503 | [1] | COVER | |
| 29 | 1U-8846 B | SEALANT-GASKET | ||
| 30 | 096-3216 M | [2] | SETSCREW-SOCKET (M12X1.75X12-MM) | |
| 31 | 191-2571 | [1] | CARRIER-PLANETARY | |
| 32 | 169-5601 | [3] | SHAFT-PLANETARY | |
| 33 | 169-5592 | [3] | GEAR-PLANETARY (23-TEETH) | |
| 34 | 094-1528 | [12] | WASHER (53X84X1-MM THK) | |
| 35 | 095-0891 | [6] | PIN-SPRING | |
| 36 | 169-5593 | [3] | GEAR-PLANETARY (23-TEETH) | |
| 37 | 191-2569 | [3] | BEARING AS (CAGED ROLLER) | |
| 38 | 169-5602 | [3] | SHAFT-PLANETARY | |
| 39 | 169-5608 | [1] | HOUSING | |
| B | USE AS REQUIRED | |||
| M | METRIC PART | |||
| Z | NOT SERVICED SEPARATELY | |||
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
