Home ProductsExcavator Swing Gearbox

31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type

31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type

  • 31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type
  • 31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type
31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Swing Gearbox Part Number: 31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8
Used For: R220LC-9S R220-9 Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

R220-9 Swing Reduction Gear

,

31Q6-10151SG8 Swing Reduction Gear

,

31Q6-10151 Swing Reduction Gear

31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type2&3

Part Name Swing Gearbox
Part No. 31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8
Used For R220LC-9S R220-9
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
N*. @ [1] SWING MOTOR ASSY SEE 4100
*-2. 31Q6-10140 [1] SWING REDUCTION GEAR
*-2. 31Q6-10141 [1] SWING REDUCTION GEAR
*-2. 31Q6-10141AR [1] SWING REDUCTION GEAR
1 XKAQ-00771 [1] CASING
1 XKAQ-00962 [1] CASING
2 XKAQ-00403 [1] SHAFT-DRIVE
2 XKAQ-00780 [1] SHAFT-DRIVE
3 XKAQ-00018 [1] SPACER
4 XKAQ-00026 [1] BEARING-ROLLER
5 XKAQ-00032 [1] SEAL-OIL
6 XKAQ-00029 [1] BEARING-ROLLER
6 XKAQ-00647 [1] BEARING-ROLLER
6 XKAQ-00961 [1] BEARING-ROLLER
7 XKAQ-00404 [1] PLATE-THRUST
8 XKAQ-00753 [1] CARRIER ASSY 2 NOT SHOWN
9 XKAQ-00075 [1] CARRIER 2
10 XKAQ-00023 [3] GEAR-PLANET 2
11 XKAQ-00643 [3] PIN ASSY 2 NOT SHOWN
12 XKAQ-00070 [3] PIN 2 INLC 13
N13. XKAQ-00291 [1] BUSHING 2
14 XKAQ-00071 [6] WASHER-THRUST
15 XKAQ-00048 [2] PIN-SPRING
16 XKAQ-00405 [1] GEAR-SUN 2
16 XKAQ-00755 [1] GEAR-SUN 2
17 XKAQ-00754 [1] CARRIER ASSY 1 NOT SHOWN
15 XKAQ-00048 [3] PIN-SPRING
18 XKAQ-00531 [1] CARRIER 1
19 XKAQ-00025 [3] GEAR-PLANET 1
20 XKAQ-00532 [3] PIN 1
20 XKAQ-00415 [3] PIN 1
21 XKAQ-00030 [3] CAGE-NEEDLE
22 XKAQ-00057 [3] PLATE-SIDE 1
23 XKAQ-00040 [3] PLATE-SIDE 2
24 XKAQ-00041 [3] RING-STOP
25 XKAQ-00010 [1] GEAR-SUN 1
26 XKAQ-00534 [1] PLATE-SIDE 3
27 XKAQ-00529 [1] GEAR-RING
27 XKAQ-00779 [1] GEAR-RING
28 XKAQ-00977 [1] GEAR-PINION
29 XKAQ-00074 [1] RING-STOP
30 XKAQ-00072 [2] PIN-KNOCK
31 XKAQ-00065 [12] BOLT-SOCKET
32 XKAQ-00031 [1] PLATE-COVER
33 XKAQ-00064 [8] BOLT-HEX
34 XKAQ-00043 [1] PLATE-LOCK
35 XKAQ-00042 [2] BOLT-HEX
36 XKAQ-00292 [1] WASHER-LOCK
37 XKAQ-00049 [1] PLUG
38 XKAQ-00066 [2] PLUG
*-1. @ [1] SWING MOTOR UNIT SEE 4100
N. @ [AR] NOT SUPPLIED PARTS



31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 0

31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 1



31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 231Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 3







FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.



31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 431Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 531Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 631Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 731Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 831Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 9

31Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 1031Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 1131Q6-10140 39Q6-12100 31Q6-10151 38Q5-10151 31Q6-10151SG8 R220LC-9S R220-9 Swing Reduction Gear Type 12
