Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 148-4644 148-4679 1912682 2276035 2813588 3530615 E320C E320D E320D2 E315C
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden Case
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Swing Gearbox Part Number: 148-4644 148-4679 1912682 2276035 2813588 3530615
Used For: E320C E320D E320D2 E315C Condiction: All New
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR
Port: Huangpu After Warranty Service: Online Support Spare Parts
High Light:

E315C Excavator Swing Gear Box

,

3530615 Excavator Swing Gear Box

,

2813588 Excavator Swing Gearbox

148-4644 148-4679 1912682 2276035 2813588 3530615 E320C E320D E320D2 E315C Excavator Swing Gear Box Reduction



Part Name Swing Gearbox
Part No. 148-4644 148-4679 1912682 2276035 2813588 3530615
Used For E320C E320D E320D2 E315C
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
1 094-0584 [6] WASHER (40.3X72X1-MM THK)
2 094-1509 [3] SHAFT-PLANETARY
3 148-4733 [3] GEAR-PLANETARY (26-TEETH)
4 114-1581 [1] SPACER (57.5X74X6-MM THK)
5 148-4732 [1] GEAR-SUN (20-TEETH)
6 093-1729 [2] RING-RETAINING
7 148-4632 [1] GEAR-SUN (23-TEETH)
8 191-2578 [1] CARRIER-PLANETARY
9 7Y-1434 [1] SPACER (40X69.5X6-MM THK)
10 148-4637 [1] CARRIER-PLANETARY
11 148-4640 [1] RING-RETAINING
12 148-4643 [1] BEARING
13 095-1022 [1] BEARING-ROLLER
14 148-4642 [1] SEAL-O-RING
15 227-6228 [1] CAGE
16 453-3447 M [6] BOLT (M12X1.75X40-MM)
17 451-2182 [6] WASHER-HARD (13.5X25.5X3-MM THK)
18 199-4561 [2] SEAL-LIP TYPE
19 148-4636 [1] SHAFT-PINION
20 148-4638 [1] HOUSING
21 3K-0360 [1] SEAL-O-RING
22 6V-7238 [1] VALVE-SHUTOFF (SWING DRIVE)
23 148-4634 [3] SHAFT-PLANETARY
24 095-0891 [3] PIN-SPRING
25 148-4635 [1] GEAR-RING (73-TEETH)
26 148-4633 [3] GEAR-PLANETARY (25-TEETH)
27 7Y-0252 [6] BEARING AS-ROLLER
28 094-0611 [6] WASHER (47.3X76X1-MM THK)
29 095-0886 [3] PIN-SPRING
30 094-1516 [3] BEARING-ROLLER
31 171-9383 [1] SPACER

  1U-8846 BF   SEALANT-GASKET
  B   USE AS REQUIRED
  F   NOT SHOWN
  M   METRIC PART



148-4644 148-4679 1912682 2276035 2813588 3530615 E320C E320D E320D2 E315C Excavator Swing Gear Box Reduction 0



148-4644 148-4679 1912682 2276035 2813588 3530615 E320C E320D E320D2 E315C Excavator Swing Gear Box Reduction 1

148-4644 148-4679 1912682 2276035 2813588 3530615 E320C E320D E320D2 E315C Excavator Swing Gear Box Reduction 2148-4644 148-4679 1912682 2276035 2813588 3530615 E320C E320D E320D2 E315C Excavator Swing Gear Box Reduction 3148-4644 148-4679 1912682 2276035 2813588 3530615 E320C E320D E320D2 E315C Excavator Swing Gear Box Reduction 4148-4644 148-4679 1912682 2276035 2813588 3530615 E320C E320D E320D2 E315C Excavator Swing Gear Box Reduction 5148-4644 148-4679 1912682 2276035 2813588 3530615 E320C E320D E320D2 E315C Excavator Swing Gear Box Reduction 6




FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.
