206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly

206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly

  • 206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly
  • 206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly
  • 206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly
  • 206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly
  • 206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly
206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Swing Gearbox Part Number: 206-26-00401 206-26-00400 206-26-71490 206-25-00320
Used For: PC220-7 PC240-8 Condiction: All New
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR
Port: Huangpu After Warranty Service: Online Support Spare Parts
High Light:

PC240-8 Gearbox Assembly

,

206-25-00320 Gearbox Assembly

,

206-26-00401 Gearbox Assembly

206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly



Part Name Swing Gearbox
Part No. 206-26-00401 206-26-00400 206-26-71490 206-25-00320
Used For PC220-7 PC240-8
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
  206-26-00401 [1] SWING MACHINERY A. Komatsu 226.1 kg.
  ["SN: 60601-@"] analogs:["2062600400"] |$2.
  206-26-00400 [1] SWING MACHINERY A. Komatsu 226.1 kg.
  ["SN: 60001-60600"] analogs:["2062600401"] |$3.
1. 206-26-71490 [1] Komatsu 105.42 kg.
  ["SN: 60001-60600"]
2. 07029-00000 [1] VALVE Komatsu 0.09 kg.
  ["SN: 60001-60600"] analogs:["6127613890"]
3. 20Y-26-22330 [1] BEARING Komatsu China 3.28 kg.
  ["SN: 60001-60600"] analogs:["20Y2622331", "20Y2622430"]
4. 206-26-71240 [1] BEARING Komatsu 12.83 kg.
  ["SN: 60001-60600"]
5. 206-26-71460 [1] SHAFT Komatsu China
  ["SN: 60001-60600"]
6. 07012-00115 [1] SEAL Komatsu 0.127 kg.
  ["SN: 60001-60600"]
7. 206-26-71310 [1] SPACER Komatsu 0.81 kg.
  ["SN: 60001-60600"]
8. 07000-15310 [1] O-RING Komatsu China 0.035 kg.
  ["SN: 60001-@"] analogs:["0700005310"]
9. 206-26-71480 [1] CARRIER Komatsu 10.88 kg.
  ["SN: 60001-@"]
10. 206-26-71440 [4] GEAR Komatsu 1.91 kg.
  ["SN: 60001-@"]
11. 22U-26-21320 [8] BEARING Komatsu 1.1 kg.
  ["SN: 60036-@"]
11. 22U-26-21330 [8] BEARING Komatsu China
  ["SN: 60001-60035"]
12. 206-26-71520 [8] THRUST WASHER Komatsu 0.1 kg.
  ["SN: 60001-@"]
13. 206-26-71510 [4] PIN Komatsu 0.97 kg.
  ["SN: 60001-@"]
14. 20Y-26-21330 [4] PIN Komatsu China 0.1 kg.
  ["SN: 60001-@"]
15. 20Y-26-21240 [1] PLATE Komatsu 5.1 kg.
  ["SN: 60001-@"]
16. 112-32-11211 [1] BOLT Komatsu 0.09 kg.
  ["SN: 60001-@"]
17. 206-26-71452 [1] GEAR Komatsu 28.79 kg.
  ["SN: 60283-@"]
17. 206-26-71450 [1] GEAR Komatsu 28.79 kg.
  ["SN: 60001-60282"] analogs:["2062671452"]
18. 20K-22-11190 [1] O-RING Komatsu 0.02 kg.
  ["SN: 60001-@"] analogs:["20G2211190"]
19. 01010-81440 [22] BOLT Komatsu 0.073 kg.
  ["SN: 60001-@"] analogs:["0101061440", "0101031440", "0101051440", "0104031440"]
20. 01643-31445 [22] WASHER Komatsu 0.019 kg.
  ["SN: 60001-@"] analogs:["0164301432"]
21. 206-26-71430 [1] GEAR Komatsu 2.33 kg.
  ["SN: 60001-@"]
22. 04260-01270 [1] BALL Komatsu OEM 0.009 kg.
  ["SN: 60001-@"]
23. 206-26-71470 [1] CARRIER Komatsu 3.9 kg.
  ["SN: 60001-@"]
24. 206-26-71420 [3] GEAR Komatsu 0.83 kg.
  ["SN: 60001-@"]
25. 20Y-27-22210 [3] BEARING Komatsu China 0.12 kg.
  ["SN: 60001-@"] analogs:["20Y2721260"]
26. 22U-26-21230 [6] WASHER,THRUST Komatsu 1 kg.
  ["SN: 60001-@"]
27. 206-26-71210 [3] PIN Komatsu 0.42 kg.
  ["SN: 60001-@"]
28. 04064-03515 [6] RING Komatsu 0.005 kg.
  ["SN: 60001-@"]
29. 206-26-71350 [1] HOLDER Komatsu 0.21 kg.
  ["SN: 60001-@"]
30. 206-26-71410 [1] GEAR Komatsu 0.83 kg.
  ["SN: 60001-@"]
31. 206-26-71341 [1] PLATE Komatsu China
  ["SN: 60593-@"]
31. 206-26-71340 [1] PLATE Komatsu 0.09 kg.
  ["SN: 60001-@"]
32. 20Y-26-31510 [1] COVER Komatsu 7.3 kg.
  ["SN: 60001-@"]
33. 01010-81035 [6] BOLT Komatsu 0.033 kg.
  ["SN: 60001-@"] analogs:["801015556", "01010D1035", "0101051035"]
34. 01643-51032 [6] WASHER Komatsu 0.17 kg.
  ["SN: 60001-@"] analogs:["R0164351032"]
35. 07042-30617 [1] PLUG Komatsu China
  ["SN: 60001-@"]
36. 07042-30108 [1] PLUG Komatsu 0.008 kg.
  ["SN: 60001-@"] analogs:["0704220108"]
37. 07042-30415 [1] PLUG Komatsu 0.056 kg.
  ["SN: 60001-@"]



206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly 0

206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly 1








FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.

206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly 2206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly 3206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly 4206-26-00401 206-26-00400 206-26-71490 206-25-00320 PC220-7 PC240-8 Swing Construction Machinery Parts Gearbox Assembly 5
