Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: K1000350 K1033589 404-00091 K9005007K1002518 K9005202 DX480 DH500 DX520
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Swing Gearbox Part Number: K1004160A 404-00097C 404-00062 104-00043 104-00046
Used For: DH300-7 DH225-7 SOLAR 225LC-7A SOLAR 225LC-V Condiction: All New
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR
Port: Huangpu After Warranty Service: Online Support Spare Parts
High Light:

225LC-V Swing Gearbox

,

DH300-7 Swing Gearbox

,

104-00046 Swing Gearbox

K1004160A 404-00097C 404-00062 104-00043 104-00046 DH300-7 DH225-7 SOLAR 225LC-7A SOLAR 225LC-V Swing Gearbox

Part Name Swing Gearbox
Part No. K1004160A 404-00097C 404-00062 104-00043 104-00046
Used For DH300-7 DH225-7 SOLAR 225LC-7A SOLAR 225LC-V
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
-. 130426-00004 [1] GEAR ASSY,REDUCTION
-. K1004160A [1] GEAR;REDUCTION 130426-00004
1 2423-1496G [1] CASING
10 230-00061 [1] CARRIER NO.2
11 2114-1901A [4] WASHER;THRUST NO.2
12 104-00050 [4] GEAR;PLANET NO.2
13 110-00219 [4] BUSH NO.2
14 123-00437A [4] PIN NO.2
15 S5741341 [4] PIN;SPRING
16 S0121061 [1] BOLT
17 114-00548 [1] WASHER;THRUST NO.3
18 104-00048 [1] GEAR;SUN NO.2
19 2705-1030 [4] PIN;KNOCK
2 2112-1248E [1] SHAFT;DRIVE
20 100502-00001 [1]
20 230-00060A [1] CARRIER NO.1
21 114-00527 [4] WASHER;THRUST NO.1
21 114-00527 [3] WASHER;THRUST NO.1
22 130424-00001 [4]
22 104-00049A [3] GEAR;PLANET NO.1
23 120501-00009 [4]
23 123-00435A [3] PIN ASS'Y NO.1
24 120107-00002 [16]
24 S2217471 [16] BOLT;SOCKET
25 130425-00001 [1]
25 104-00047A [1] GEAR;SUN NO.1 130425-00001
26 S6500450 [1] RING;SNAP
27 2181-1116D2 [2] PLUG
28 2181-1116D4 [1] PLUG
29 2140-1406 [1] PIPE;LEVEL GAUGE
3 2412-1040 [1] PLATE
30 2119-1065 [1] GAUGE;LEVEL
31 120811-00001 [1]
31 S5231090 [1] WASHER;DOUBLE TAP
32 140-01374A [4] PIPE
33 120-00144 [8] BOLT
34 120816-00001 [1]
4 2109-9033 [1] BEARING;ROLLER
5 2891-1421B [1] PLATE;COVER
51 100502-00022 [1]
51 K9006810 [1] CARRIER NO1 ASS'Y
52 K9006811 [1] CARRIER NO2 ASS'Y
6 S6500380 [4] RING;SNAP
6 S6500380 [3] RING;SNAP
7 2180-1254 [1] SEAL;OIL
8 109-00174 [1] BEARING;ROLLER
9 130422-00001 [1]
9 104-00051A [1] GEAR;RING



K1004160A 404-00097C 404-00062 104-00043 104-00046 DH300-7 DH225-7 SOLAR 225LC-7A SOLAR 225LC-V Swing Gearbox 0

K1004160A 404-00097C 404-00062 104-00043 104-00046 DH300-7 DH225-7 SOLAR 225LC-7A SOLAR 225LC-V Swing Gearbox 1

K1004160A 404-00097C 404-00062 104-00043 104-00046 DH300-7 DH225-7 SOLAR 225LC-7A SOLAR 225LC-V Swing Gearbox 2K1004160A 404-00097C 404-00062 104-00043 104-00046 DH300-7 DH225-7 SOLAR 225LC-7A SOLAR 225LC-V Swing Gearbox 3








FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.
