20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy

20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy

  • 20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy
  • 20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy
20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Carrier Part Number: 20Y-27-22160 20Y-26-21150 20Y-26-21160 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG
Used For: PC200-6 Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/TNT/UPS/SEA/AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

1St Travel Carrier Assy

,

BR200S Travel Carrier Assy

,

20Y-27-22160 Travel Carrier Assy

20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy Final Drive Part Carrier Gear



Part Name Carrier Gear
Part No. 20Y-27-22160 20Y-26-21150 20Y-26-21160
Used For PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
1 708-8F-00111 [2] MOTOR ASS'Y Komatsu 102.801 kg.
  ["SN: 110673-UP"] analogs:["7088F00110"]
1 708-8F-00110 [2] MOTOR ASS'Y Komatsu 102.801 kg.
  ["SN: 98409-110672"] analogs:["7088F00111"]
1 708-8F-00061 [2] MOTOR ASS'Y Komatsu China
  ["SN: 97792-98408"] analogs:["7088F00060"]
    [-1] (708-8F-00110,20Y-27-22181,20Y-27-22261)
  |$$4.
1 708-8F-00060 [2] MOTOR ASS'Y Komatsu China
  ["SN: 91087-97791"] analogs:["7088F00061"]
  150-27-00330 [2] FLOATING SEAL ASS'Y Komatsu China 2.99 kg.
  ["SN: 99850-UP"] analogs:["1502700029", "1502700410"] |$17.
  150-27-00029 [2] FLOATING SEAL ASS'Y Komatsu China 2.99 kg.
  ["SN: 83115-99849"] analogs:["1502700330", "1502700410"] |$18.
4 20Y-27-22181 [2] HUB Komatsu 78 kg.
  ["SN: 98409-UP"]
4 20Y-27-22180 [2] HUB Komatsu China
  ["SN: 91087-98408"]
5 20Y-27-22230 [4] BEARING Komatsu 4.6 kg.
  ["SN: 91087-UP"]
6 20Y-27-22280 [2] O-RING Komatsu China 0.02 kg.
  ["SN: 91087-UP"]
7 20Y-27-22261 [2] LOCK Komatsu 5.22 kg.
  ["SN: 98409-UP"]
7 20Y-27-22260 [2] LOCK Komatsu 4.05 kg.
  ["SN: 91087-98408"]
8 20Y-27-22270 [2] LOCK Komatsu 0.07 kg.
  ["SN: 91087-UP"]
9 01010-81020 [4] BOLT Komatsu 0.161 kg.
  ["SN: 91087-UP"] analogs:["801014093", "0101051020", "801015108"]
10 20Y-27-22170 [2] CARRIER Komatsu China 20.4 kg.
  ["SN: 91087-UP"]
11 20Y-27-22140 [8] GEAR Komatsu China 3.72 kg.
  ["SN: 91087-UP"]
12 20Y-27-22220 [8] BEARING Komatsu China 0.3 kg.
  ["SN: 91087-UP"] analogs:["20Y2721270"]
13 20Y-27-21250 [16] WASHER Komatsu China 0.03 kg.
  ["SN: 91087-UP"]
14 20Y-27-21230 [8] PIN Komatsu 1.54 kg.
  ["SN: 91087-UP"]
15 20Y-27-21290 [8] PIN Komatsu OEM 0.03 kg.
  ["SN: 91087-UP"]
16 20Y-27-13310 [2] WASHER Komatsu China 0.08 kg.
  ["SN: 80001-UP"]
17 20Y-27-22130 [2] GEAR Komatsu China 1.75 kg.
  ["SN: 91087-UP"]
18 20Y-27-22240 [2] WASHER Komatsu China 0.03 kg.
  ["SN: 91087-UP"]
19 20Y-27-22150 [2] GEAR Komatsu 43.7 kg.
  ["SN: 91087-UP"] analogs:["20Y2722151"]
20 20Y-27-22160 [2] CARRIER Komatsu OEM 6 kg.
  ["SN: 91087-UP"]
21 20Y-27-22120 [6] GEAR Komatsu China 2.5 kg.
  ["SN: 91087-UP"]
22 20Y-27-22210 [6] BEARING Komatsu China 0.12 kg.
  ["SN: 91087-UP"] analogs:["20Y2721260"]
23 20Y-27-21240 [12] WASHER Komatsu China 0.02 kg.
  ["SN: 80001-UP"]
24 20Y-27-21220 [6] PIN Komatsu China 0.411 kg.
  ["SN: 80001-UP"]
25 20Y-27-21280 [6] PIN Komatsu China 0.01 kg.
  ["SN: 80001-UP"]
26 20Y-27-22110 [2] SHAFT Komatsu China 1.4 kg.
  ["SN: 91087-UP"] analogs:["20Y2731140"]
27 20Y-27-21310 [2] WASHER Komatsu China 0.17 kg.
  ["SN: 80001-UP"]
28 20Y-27-22250 [2] BUTTON Komatsu China 0.05 kg.
  ["SN: 91087-UP"]
29 20Y-27-22190 [2] COVER Komatsu 17.6 kg.
  ["SN: 91087-UP"]
30 20Y-27-13281 [36] BOLT Komatsu 0.31 kg.
  ["SN: 91087-UP"]
31 01643-31645 [36] WASHER Komatsu 0.072 kg.
  ["SN: 80001-UP"] analogs:["802170005", "0164301645"]
32 07049-01012 [4] PLUG Komatsu 0.001 kg.
  ["SN: 91087-UP"]
33 07044-12412 [4] PLUG Komatsu 0.09 kg.
  ["SN: 80001-UP"] analogs:["0704402412", "R0704412412"]
34 07002-02434 [4] O-RING Komatsu China 0.01 kg.
  ["SN: 80001-UP"] analogs:["0700212434", "0700213434"]
35 20Y-27-11582 [2] SPROCKET Komatsu China 36.2 kg.
  ["SN: 108386-UP"] analogs:["20Y2711581", "20Y27K1110", "20Y2777110"]
35 20Y-27-11581 [2] SPROCKET Komatsu China 36.2 kg.
  ["SN: 80001-108385"] analogs:["20Y2711582", "20Y27K1110", "20Y2777110"]
36 20Y-27-11561 [40] BOLT Komatsu China 0.14 kg.
  ["SN: 80001-UP"]
37 01010-61660 [36] BOLT Komatsu 0.127 kg.
  ["SN: 92578-UP"] analogs:["0101031660", "0101081660"]
37 01010-61670 [36] BOLT Komatsu 0.142 kg.
  ["SN: 91087-92577"] analogs:["0101031670", "0101051670", "0101081670"]
39 20Y-30-21191 [2] COVER Komatsu 12.25 kg.
  ["SN: 106778-UP"]
39 20Y-30-21190 [2] COVER Komatsu China
  ["SN: 91087-106777"]
40 01010-81230 [8] BOLT Komatsu 0.043 kg.
  ["SN: 91087-UP"] analogs:["0101051230", "01010B1230"]
41 01643-31232 [8] WASHER Komatsu 0.027 kg.
  ["SN: 91087-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]

20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 0





20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 1

20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 220Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 3









FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount),Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all ,we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely , or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass’y/parts, swing gearbox/ass’y. If you need other excavator parts, we also can supply as your requirements.

20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 420Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 520Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 620Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 720Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 820Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 9

20Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 1020Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 1120Y-27-22160 20Y-26-21150 20Y-26-21160 PC200-6 6D102 BR200J BR200S BR200T BR250RG BR300J BR310JG 1St Travel Carrier Assy 12
