YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing

YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing

  • YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing
  • YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing
  • YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing
  • YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing
YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden Case
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Housing Part Number: YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271
Used For: SK200-8 SK210D-8 SK215SRLC Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

SK215SRLC Case Swing Motor Housing

,

SK200-8 Case Swing Motor Housing

,

YN15V00035S301 Case Swing Motor Housing

YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing

Part Name Housing
Part No. YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271
Used For SK200-8 SK210D-8 SK215SRLC
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
51 YN22V00014FA [2] VALVE KOB Relief (Includes ZD12G03000)
. . ZD12G03000 [1] O-RING,29.40mm ID x 35.60mm OD x 3.10mm KOB ID 29.4 ± 0.29 x OD 35mm (Part Of Ref 51)
52 YN20V00004F1 [1] VALVE KOB Assy - See Fig. 07-001[02]
101 YN15V00025S101 [1] SHAFT KOB
111 YN15V00025S111 [1] CYLINDER KOB
114 YN15V00025S114 [1] SPRING KOB
121 NSS [1] NOT SOLD SEPARAT CON PISTON
122 NSS [1] NOT SOLD SEPARAT CON SHOE
123 YN15V00025S123 [1] PLATE KOB
124 YN15V00025S124 [1] PLATE KOB
131 YN15V00025S131 [1] PLATE KOB
301 YN15V00035S301 [1] BOX SM CASE
303 NSS [1] NOT SOLD SEPARAT CON CASE
351 YN15V00025S351 [2] SPOOL KOB
355 YN15V00002S355 [2] SPRING KOB
390 NSS [1] NOT SOLD SEPARAT CON NAME PLATE
391 2437U407S983 [2] RIVET KOB
401 ZS23C20045 [4] CAP,Hex Socket Head, M20 x 45mm KOB Screw -- M20x2.5x45mm
443 YN15V00002S011 [1] ROLLER BEARING KOB
444 LQ15V00008S010 [1] ROLLER BEARING KOB
451 NSS [1] NOT SOLD SEPARAT CON PIN
469 YN15V00002S012 [2] PLUG KOB PLUG
472 YN15V00025S489 [1] O-RING,3.5mm Thk x 173mm ID, 75 Duro KOB
488 ZD12P02800 [2] O-RING KOB ID 27.70 ± 0.27 x OD 34mm
491 YN15V00035S491 [1] OIL SEAL SM OIL SEAL
702 YN15V00002S014 [1] PISTON KOB
706 2441U736S706 [1] O-RING KOB
707 2415U188S707 [1] O-RING KOB
712 YN15V00025S712 [18] SPRING,ID1.1mm : OD1.8mm : W=3.7mm (this is spring) KOB
742 YN15V00025S742 [3] PLATE,ID14mm : OD15.5mm : W=1.7mm KOB
743 YN15V00025S743 [4] PLATE,ID14mm : OD15.5mm : W=2mm KOB
980 YN15V00035S980 [1] PLUG SM PLUG
984 YN15V00035S984 [1] PLUG SM PLUG
985 YN15V00035S985 [3] PLUG SM PLUG
993 ZE82T08000 [1] PLUG KOB 1/2" PT
994 ZE82T12000 [1] PLUG KOB 3/4" PT
. . YN15V00025R100 [1] REPAIR KIT KOB CONSISTS OF ITEMS - 121X9, 122X9
. . YN15V00025R200 [1] REPAIR KIT KOB CONSISTS OF ITEMS - 303X1, 451X2
. . YN15V00025R400 [1] REPAIR KIT KOB CONSISTS OF ITEMS - 472X1, 488X2, 491X1, 706X1, 707X1

YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 0

YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 1

YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 2YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 3YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 4YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 5









FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.



YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 6YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 7YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 8YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 9YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 10YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 11

YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 12YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 13YN15V00035S301 YN32W01104P1 YN02C03747P1 YN10V00043S271 SK200-8 SK210D-8 SK215SRLC Case Swing Motor Housing 14
