YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3

YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3

  • YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3
YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: YB60000249 YB60000075 9251681 9299482 ZX870-3 ZX850-3
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Travel Gearbox Part Number: YB60000249 YB60000075 9251681 9299482
Used For: ZX870-3 ZX850-3 Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
After Warranty Service: Video Technical Support Online Support Free Spare Parts
High Light:

YB60000249 Excavator Travel Gearbox

,

YB60000075 Excavator Travel Gearbox

,

ZX870-3 9251681

YB60000249 YB60000075 9251681 9299482 Hydraulic Excavator ZX870-3 ZX850-3 Travel Gearbox





Pos. Part No Qty Parts name Comments
00-66. 9251681 [1] TRAVEL DEVICE
0 4636857 [1] MOTOR;OIL
2 4219329 [1] BRG.;ROL.
3 4219328 [1] BRG.;ROL.
4 1030160 [1] HOUSING
5 1012131 [1] DRUM
6 2025832 [1] SUPPORT
9 4245703 [1] SEAL;GROUP
11 J932785 [24] BOLT
12 A590927 [24] WASHER;SPRING
13 425175 [2] CORK
14 4430291 [1] SPROCKET
15 3069875 [1] NUT
16 3041462 [1] PLATE;LOCK
17 J901225 [2] BOLT
18 4609016 [12] BOLT;SEMS
19 1028874 [1] CARRIER
20 3090709 [4] GEAR;PLANETARY
21 4464369 [8] BRG.;NEEDLE
22 4219640 [8] PLATE;THRUST
23 4447037 [4] PIN
24 4222029 [4] PIN;SPRING
25 3090710 [1] GEAR;SUN
27 1028886 [1] GEAR;RING
28 4223568 [1] O-RING
29 M342260 [30] BOLT;SOCKET
31 1028881 [1] CARRIER
33 3090930 [4] GEAR;PLANETARY
34 4455088 [4] BRG.;NEEDLE Y 4371402
34 4371402 [4] BRG.;NEEDLE
35 4269470 [8] PLATE;THRUST
36 4447032 [4] PIN
37 4203180 [4] PIN;SPRING
38 3090711 [1] GEAR;SUN
39 4657080 [3] SPACER
40 1028898 [1] CARRIER
42 3089538 [3] GEAR;PLANETARY
43 4445529 [3] BRG.;NEEDLE
44 4210851 [6] PLATE;THRUST
45 4309995 [3] PIN
46 4246358 [3] PIN;SPRING
47 2045895 [1] SHAFT;PROP.
49 1028899 [1] COVER
50 4284195 [1] BRG.;BALL
51 4277474 [1] PIN;STOPPER
54 4257967 [18] BOLT;SHOE
55 A590914 [18] WASHER;SPRING
56 4462824 [3] PLUG
57 429597 [2] CORK
61 4271596 [1] O-RING
62 J911860 [4] BOLT
63 A590918 [4] WASHER;SPRING
65 +++++++ [1] NAME-PLATE
66 M492564 [2] SCREW;DRIVE
101 4279079 [2] PLATE
102 4279078 [2] PACKING
103 J901216 [4] BOLT
104 3096382 [1] COVER
105 J931835 [4] BOLT
201 9219275 [1] T.MISSION (WITHOUT MOTOR) (ITEM 02-61,104-105)
202 YB60000075 [1] TRAVEL DEVICE (WITHOUT SPROCKET) (ITEM 00-09,15-66,101-103)
203 YB60000249 [1] TRAVEL DEVICE (WITHOUT MOTOR,SPROCKET) (ITEM 02-09,15-61,104-105)





YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3 0

YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3 1




FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.



YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3 2

YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3 3YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3 4YB60000249 YB60000075 9251681 9299482 Excavator Travel Gearbox For ZX870-3 ZX850-3 5
