LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier

LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier

  • LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier
  • LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier
LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: LG200 2nd Carrier
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden Case
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Planet Carrier Part Number: LG200 2nd
Used For: LG200 Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/TNT/UPS/SEA/AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

LG200 2nd Level Reduction Gear

,

Reduction Gear Assembly

,

LG200 Planet Carrier

LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier



Part Name 2nd Carrier
Part No. LG200
Used For LG200
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts

        产品标题



Pos. Part No Qty Parts name Comments
  VOE14540907 [1] Swing gearbox
1 VOE14566995 [1] Case
2 VOE14588466 [1] Gear
3 SA7118-34510 [1] Adapter
4 VOE14529015 [1] Valve
5 VOE984358 [10] Hex. socket screw
6 VOE14528928 [1] Shaft
7 SA7118-23330 [1] Seal
8 SA7118-23310 [1] Collar
9 VOE990592 [1] O-ring
10 SA7118-23270 [1] Roller bearing
11 SA7118-23280 [1] Roller bearing
12 SA7118-23520 [2] Collar
13 SA9324-21212 [2] Pin
14 SA7118-23200 [1] Planet carrier
15 SA7118-23210 [1] Planet carrier
16 SA7118-23240 [3] Pin
17 SA7147-00150 [6] Thrust washer
18 SA7118-23250 [3] Bushing
19 SA9325-06012 [3] Spring pin
20 SA7118-23220 [3] Planetary gear
21 SA7118-23390 [1] Sun gear
22 SA7118-23490 [1] Gear
23 SA1036-00120 [1] Thrust washer
24 SA7118-23400 [1] Planet carrier
25 SA7118-23410 [1] Planet carrier
26 SA7118-23430 [1] Pin
27 SA9325-06012 [3] Spring pin
28 SA7147-00150 [3] Thrust washer
29 SA7118-23460 [3] Washer
30 SA7118-23440 [3] Needle bearing
31 SA7118-23420 [3] Planetary gear
32 VOE914462 [3] Snap ring



LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 0

LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 1



LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 2LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 3







FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.





LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 4LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 5LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 6LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 7LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 8LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 9

LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 10LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 11LG200 2nd Level Reduction Gear Planetary Gear Assembly Swing Gearbox 2nd Carrier 12
