DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A

DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A

  • DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A
  • DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A
  • DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A
  • DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A
  • DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A
DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 104-00047A 104-00050 104-00051A DX225 DX180 DH500
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden Case
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Cover Part Number: 104-00047A 104-00050 104-00051A DX225 DX180
Used For: DX225 DX180 DH500 Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/TNT/UPS/SEA/AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

DH500 Swing Gearbox Sun Gear

,

 104-00051A Swing Gearbox Sun Gear

,

DX225 Swing Gearbox Sun Gear

104-00047A 104-00050 104-00051A DX225 DX180 DH500 Planetary Gear Parts Swing gearbox Sun gear NO.1

Part Name Sun gear NO.1
Part No. 104-00047A 104-00050 104-00051A
Used For DX225 DX180
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
-. K1013561 [1] REDUCTION GEAR
1 K1001235 [1] CASING
10 230-00061 [1] CARRIER NO.2
11 2114-1901A [4] WASHER;THRUST NO.2
12 104-00050 [4] GEAR;PLANET NO.2
13 110-00219 [4] BUSH NO.2
14 123-00437A [4] PIN NO.2
15 S5741341 [4] PIN;SPRING
16 S0121061 [1] BOLT
17 114-00548 [1] WASHER;THRUST NO.3
18 104-00048 [1] GEAR;SUN NO.2
19 2705-1030 [4] PIN;KNOCK
2 105-00001A [1] SHAFT;DRIVE
20 230-00060A [1] CARRIER NO.1
21 114-00527 [3] WASHER;THRUST NO.1
22 104-00049A [3] GEAR;PLANET NO.1
23 123-00435A [3] PIN ASS'Y NO.1
24 S2217471 [16] BOLT;SOCKET
25 104-00047A [1] GEAR;SUN NO.1
26 S6500450 [1] RING;SNAP
27 2181-1116D2 [2] PLUG
28 2181-1116D4 [1] PLUG
29 2140-1406 [1] PIPE;LEVEL GAUGE
3 2412-1040 [1] PLATE
30 2119-1065 [1] GAUGE;LEVEL
31 S5231090 [1] WASHER;DOUBLE TAP
32 140-01374A [4] PIPE
33 120-00144 [8] BOLT
34 2114-1914A [1] SPACER
35 404-00018A [1] PINION
36 2403-4001A [1] COVER
37 S5102901 [4] . WASHER;SPRING
38 2120-1363 [4] BOLT
39 2126-9001 [1] WIRE
4 2109-9033 [1] BEARING;ROLLER
5 2891-1421B [1] PLATE;COVER
6 S6500380 [3] RING;SNAP
7 2180-1254 [1] SEAL;OIL
8 109-00174 [1] BEARING;ROLLER
9 104-00051A [1] GEAR;RING



DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A  0



DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A  1

DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A  2DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A  3DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A  4DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A  5DX225 DX180 DH500 Swing Gearbox Sun Gear NO.1 104-00047A 104-00050 104-00051A  6









FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.
