E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094

E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094

  • E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094
  • E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094
E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 0941528 6V5841 0966467 7Y1094 E320 E312C
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden Case
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: 2nd Washer Part Number: 0941528 6V5841 0966467 7Y1094
Used For: E320 E312C Condiction: All New OEM
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
Port: Huangpu Guangzhou After Warranty: Video Technical Support Online Support Spare Parts
High Light:

E312C Planetary Swing Gearbox 2nd Washer

,

E320 Swing Gearbox 2nd Washer

,

0941528 Swing Gearbox 2nd Washer

0941528 6V5841 0966467 7Y1094 E320 E312C Planetary Gear Parts Swing Gearbox 2nd Washer Swing Reduction

Part Name 2nd Washer
Part No. 0941528 6V5841 0966467 7Y1094
Used For E320 E312C
Warrenty 3 months
After Warranty

Video technical support Online support Free Spare parts



Pos. Part No Qty Parts name Comments
1 7Y-0752 B [1] SHIM (0.8-MM THK)
  7Y-0753 B [1] SHIM (1-MM THK)
  7Y-0754 B [1] SHIM (1.6-MM THK)
  267-6863 B [1] SHIM (0.75-MM THK)
  267-6864 B [1] SHIM (0.85-MM THK)
  267-6865 B [1] SHIM (0.9-MM THK)
  267-6866 B [1] SHIM (0.95-MM THK)
  267-6867 B [1] SHIM (1.2-MM THK)
  267-6868 B [1] SHIM (1.4-MM THK)
  267-6869 B [1] SHIM (1.8-MM THK)
  267-6870 B [1] SHIM (2-MM THK)
  267-6871 B [1] SHIM (2.3-MM THK)
4 094-0578 B [1] PLATE (8-MM THK)
  094-0579 B [1] PLATE (9-MM THK)
  094-0580 B [1] PLATE (10-MM THK)
7 094-1528 [12] WASHER (53X84X1-MM THK)
8 114-1540 [4] PIN-DOWEL
9 169-5589 [1] GEAR-SUN (24-TEETH)
10 169-5590 [1] GEAR-SUN (24-TEETH)
11 169-5592 [3] GEAR-PLANETARY (23-TEETH)
12 169-5593 [3] GEAR-PLANETARY (23-TEETH)
13 169-5601 [3] SHAFT-PLANETARY
14 169-5602 [3] SHAFT-PLANETARY
15 171-9387 [1] GEAR-RING (64-TEETH)
16 191-2571 [1] CARRIER-PLANETARY
17 191-2676 [1] GEAR-RING (72-TEETH)
18 191-2683 [1] GEAR-SUN (20-TEETH)
19 191-2684 [3] GEAR-PLANETARY (21-TEETH)
20 191-2686 [1] CARRIER AS
21 191-2689 [3] WASHER (34X70X1-MM THK)
22 191-2690 [3] WASHER (42.3X70X1-MM THK)
23 199-4503 [1] COVER
24 207-1571 [1] SEAL GP-DUO-CONE
  214-3570 [2] RING-TORIC
25 267-6798 [1] HOUSING
26 267-6799 [1] CARRIER-PLANETARY
27 267-6800 [1] GEAR-COUPLING
37 333-2914 [2] BALL BEARING
38 333-2916 [3] BEARING AS
39 333-2917 [6] BEARING AS
40 452-3517 [1] HOUSING-MOTOR
41 509-1886 [1] COUPLING
42 093-1731 [2] RING-RETAINING
43 095-0891 [6] PIN-SPRING
44 096-0433 [3] RING-RETAINING
45 096-3216 M [2] SETSCREW-SOCKET (M12X1.75X12-MM)
46 171-9298 [1] SEAL-O-RING
47 179-8733 M [16] BOLT (M20X2.5X170-MM)
48 296-6248 [3] BEARING AS-ROLLER
49 3E-2338 [2] PLUG-PIPE
50 7M-8485 [2] SEAL-O-RING
51 7Y-0595 [3] SPACER (58X79.6X6-MM THK)
52 7Y-5217 M [16] BOLT-SOCKET HEAD (M20X2.5X70-MM)
53 451-2176 [16] WASHER-HARD (22X35X3.5-MM THK)
54 8C-8840 [1] RING-RETAINING
55 8T-3282 [16] WASHER-HARD (22X35X3.5-MM THK)
56 101-7404 M [12] BOLT-SOCKET HEAD (M10X1.5X30-MM)

  1U-8846 BF [4] SEALANT-GASKET

      PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE NUMBER ARE NOT SERVICED SEPARATELY
  B   USE AS REQUIRED
  F   NOT SHOWN
  M   METRIC PART



E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 0



E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 1

E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 2E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 3











FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.



E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 4E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 5E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 6E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 7E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 8E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 9

E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 10E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 11E320 E312C Planetary Swing Gearbox 2nd Washer Swing Reduction 0941528 6V5841 0966467 7Y1094 12
