203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox

203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox

  • 203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox
  • 203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox
  • 203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox
203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox
Product Details:
Place of Origin: GUANGZHOU CHINA
Brand Name: MENZEH GEARS
Certification: CE
Model Number: 203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiated
Packaging Details: BOX, Wooden
Delivery Time: 1-3 working Days
Payment Terms: Western Union, T/T, L/C,ALI PAY
Supply Ability: 500 pcs per Day
Contact Now
Detailed Product Description
Part Name: Travel Gearbox Part Number: 203-27-00070 206-27-00033 20Y-27-00360
Used For: PC100 PC120-5 PC120-6 PC130-7 Condiction: All New
Warrenty: 3 Months Shipping: DHL/ TNT/ UPS/ SEA/ AIR Shipping
Port: Huangpu, Guangzhou After Warranty Service: Video Technical Support Online Support Spare Parts
High Light:

PC130-7 Final Drive

,

203-27-00070 Final Drive

,

PC120-6 Final Drive

203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox



Part Name Gearbox
Part No. 203-27-00070 206-27-00033 20Y-27-00360
Used For PC100 PC120-5 PC120-6 PC130-7
Warrenty 3 months
After Warranty Video technical support Online support Free Spare parts
Pos. Part No Qty Parts name Comments
  203-27-00070 [2] FINAL DRIVE ASS'Y Komatsu China
  ["SN: 30451-32650"] |$0.
1. 203-27-53242 [1] HUB Komatsu China
  ["SN: 30451-32650"]
2. 203-27-53270 [1] COVER Komatsu China
  ["SN: 30451-32650"]
3. 01252-41025 [12] BOLT Komatsu 0.035 kg.
  ["SN: 30451-32650"] analogs:["801105545", "0125271025"]
  130-27-00012 [1] FLOATING SEAL ASS'Y Komatsu China 1.36 kg.
  ["SN: 30451-32650"] analogs:["1302700010"] |$4.
6. 203-27-53290 [2] BEARING Komatsu China
  ["SN: 30451-32650"]
7. 203-27-53181 [1] GEAR Komatsu China
  ["SN: 30451-32650"]
8. 203-27-53280 [4] PIN Komatsu China
  ["SN: 30451-32650"]
9. 205-27-71680 [10] BOLT Komatsu China
  ["SN: 30451-32650"]
10. 203-27-53421 [1] CARRIER Komatsu China
  ["SN: 30451-32650"]
11. 203-27-53221 [1] CARRIER Komatsu China
  ["SN: 30451-32650"]
12. 203-27-53320 [3] GEAR Komatsu China
  ["SN: 30451-32650"]
13. 203-27-53450 [3] BEARING Komatsu China
  ["SN: 30451-32650"]
14. 203-27-53352 [3] SHAFT Komatsu China
  ["SN: 30451-32650"]
15. 203-27-53360 [3] HOLDER Komatsu China
  ["SN: 30451-32650"]
16. 01010-51275 [3] BOLT Komatsu 0.082 kg.
  ["SN: 30451-32650"] analogs:["0101081275"]
17. 203-27-53120 [3] GEAR Komatsu China
  ["SN: 30451-32650"]
18. 203-27-53250 [3] BEARING Komatsu China
  ["SN: 30451-32650"]
19. 203-27-53160 [3] HOLDER Komatsu China
  ["SN: 30451-32650"]
20. 203-27-53152 [3] SHAFT Komatsu China
  ["SN: 30451-32650"]
21. 01010-51055 [3] BOLT Komatsu 0.078 kg.
  ["SN: 30451-32650"] analogs:["0101081055"]
22. 203-27-53410 [1] SPACER Komatsu China
  ["SN: 30451-32650"]
23. 203-27-53310 [1] GEAR Komatsu China
  ["SN: 30451-32650"]
24. 203-27-53112 [1] PINION Komatsu China
  ["SN: 30451-32650"]
25. 04260-01111 [1] BALL Komatsu 0.006 kg.
  ["SN: 30451-32650"]
26. 203-27-53232 [1] COVER Komatsu China
  ["SN: 30451-32650"]
27. 203-27-53130 [1] RING,GEAR Komatsu China
  ["SN: 30451-32650"]
28. 203-27-53210 [1] SPACER Komatsu China
  ["SN: 30451-32650"]
29. 203-27-53480 [1] O-RING Komatsu China
  ["SN: 30451-32650"]
30. 01011-51465 [20] BOLT Komatsu 0.22 kg.
  ["SN: 30451-32650"] analogs:["0101161465", "0101181465"]
31. 01643-31445 [20] WASHER Komatsu 0.019 kg.
  ["SN: 30451-32650"] analogs:["0164301432"]
32. 07049-01012 [2] PLUG Komatsu 0.001 kg.
  ["SN: 30451-32650"]
33. 203-27-52350 [2] PLUG Komatsu China
  ["SN: 30451-32650"]
34. 07002-02434 [2] O-RING Komatsu China 0.01 kg.
  ["SN: 30451-32650"] analogs:["0700212434", "0700213434"]
35. 708-8E-00042 [1] TRAVEL MOTOR ASS'Y,(SEE FIG.6431A) Komatsu China
  ["SN: 30451-32650"] analogs:["7088E00043"]
36 01010-51650 [34] BOLT Komatsu China 0.113 kg.
  ["SN: 30451-32650"] analogs:["0101061650", "0101031650", "0101081650"]
37 01643-31645 [34] WASHER Komatsu 0.072 kg.
  ["SN: 30451-32650"] analogs:["802170005", "0164301645"]
38 203-27-51210 [2] SPROCKET Komatsu China
  ["SN: 30451-32650"]
39 203-27-51120 [30] BOLT Komatsu 4.73 kg.
  ["SN: 30451-32650"]



203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox 0

203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox 1203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox 2203-27-00070 206-27-00033 20Y-27-00360 PC100 PC120-5 PC120-6 PC130-7 Final Drive Travel Motor Reduction Gearbox 3











FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount), Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.
